Laboratories 4 and 5 - for microscopy
These laboratory spaces are intended for various microscopy. The space can also be used to prepare samples. In the room, there is also a scanner considered for imaging roots, which may be used with permission from CIRC coordinators. In addition, there are desiccators in various sizes, objective glasses and coverslips for microscopy, and needles for material fixation. There is a sink with a water tap.
Instrument
Many of these belong to the CIRC and may only be used with permission from its coordinators:
- Leica S6 E Stereo Microscope with light arms (4 units, one of which has a camera stand) with magnification from 0.63 to 40 times (CIRC).
- Leica WILD Aviopret APT 2 Stereoscope with light bench (10x/21B).
Leica WILD MS 5 Stereo Microscope with magnification from 0.63 to 4.0 times. - Leitz WILD M3C Stereo Microscope with magnification from 6.4 to 40 times.
- Askania RME 5 Transmitted Light Microscope (CIRC) with objectives: 0.25, 0.65, 1.25, 2.50 (160/0.17).
- Leitz WILD Biomed Type 020-507.010 Microscope with objective: EF 10, EF 40, EF 100 (160/0.17).
- Leitz Laborlux K Fluorescence Microscope with objectives: EF 10/0.25, EF 40/0.65, EF 100/1.25 EL.
- Leica DM IL Inverted Microscope (CIRC).
- Leica DM LB Research Grade Microscope with 10x magnification and illumination.
Facts about the microscope laboratory
Purely general laboratory
Not for chemical handling
For processed soil/plant samples
Four workbenches
